Gamber-Johnson Panasonic TOUGHBOOK 20 Docking Station - Dual RF 7160-1265-02

Item No.7160-1265-02
FEATURES Compatible with the Panasonic Toughbook 20 and G2 2-in-1 notebook computers Panasonic Toughbook Certified utilizing Panasonic Certified electronics Spring-loaded cover protects docking connector when computer is not docked, automatically retracts for superior protection Special docking conn
Suggested Retail Price $1704
Price $1192.8
excl. tax
5 in stock

Description

FEATURES
  • Compatible with the Panasonic Toughbook 20 and G2 2-in-1 notebook computers
  • Panasonic Toughbook Certified utilizing Panasonic Certified electronics
  • Spring-loaded cover protects docking connector when computer is not docked, automatically retracts for superior protection
  • Special docking connector pin protection – helps to prevent accidental pin damage by providing additional protection around and in between each docking pin
  • Can be used in either laptop or tablet orientation.
  • Composite/aluminum design for reduced weight and durability
  • Designed with rounded edges to enhance personal safety
  • Rear-facing I/O ports; integrated cable strain relief and cable management system
  • Access to all notebook control buttons and ports while the notebook is docked
  • Floating docking connector for reliable connectivity in the most rugged environments
  • Keyed lock for theft deterrence, NOTE: The lock secures the Toughbook 20 keyboard and tablet, but only secures the keyboard for the G2.
  • VESA 75 mm mounting pattern
Antenna Pass-Through
  • Dual RF (TNC)
Port Replicators
  • Panasonic certified electronics
  • (2) USB 3.0 - 9 pin
  • HDMI - 19 pin
  • Serial - D-sub 9-pin
  • Ethernet - RJ45
  • VGA D-sub -15-pin
  • Antenna switch
  • Dual RF Pass-Through (optional) - TNC
  • Power supply input - DC 15.6V-16V
Power Supply
  • Power adapter is not included, please use one of the following:
    • LIND 11-16V Auto Power Adapter with Cigarette Lighter connector (7300-0459)
    • LIND 11-16V Auto Power Adapter with Bare Wire Lead (7300-0460)
    • LIND 12-32V Material Handling Isolated Power Adapter (7300-0464)
    • LIND 20-60V Material Handling Isolated Power Adapter (7300-0465)
    • LIND 72-110V Material Handling Isolated Power Adapter (7300-0417)
Testing & Certificates
  • Toughbook Certified
  • MIL-STD 810G Shock/Vibration Tested
  • MIL-STD 810G Environmental Testing: Humidity, High/low temperature, (storage/operational)
  • Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
  • RoHS, FCC, CE, C-TICK, UKCA
  • SAE J1455 Shock Crash Hazard Test
Kit Includes
  • Panasonic Toughbook 20 Docking Station
  • Mounting Hardware
  • Installation Instructions

Specifications

Brands
Gamber Johnson
Color
Black
Compatible Computer
Panasonic TOUGHBOOK 20
Compatible Computer
Panasonic TOUGHBOOK 20
Depth
10.1"
Height
2.5"

Reviews (0)

There are no reviews yet.
